Product Introduction
Product Specifications
| Display Type: | oled display |
| Display Mode: | Passive Matrix |
| Model Number: |
HT--9632TSWEG01 |
| Diagonal Screen size: | 0.96 inch |
| Interface: |
4-wire SPI |
| Color | Monochrome(White,Yellow,Blue,Green) |
| Number of Pixels: |
128x64 |
| Active Area:: |
10.86*21.74 (mm) |
| Driver IC: |
SH1107 |
|
Operating Voltage |
1.65v~3.5v |
| Pixel Pitch: |
0.17 x 0.17(mm) |
| Pixel Size: |
0.154 x 0.154 (mm) |
|
Weight: |
1.54 (g) |
|
Operating Temperature: |
-40~+70℃ |
